Introductory Optical Bench Set Manufacturer,Supplier and Exporter in India
Product Code : EL-AP-10734
Quick Answer: The Introductory Optical Bench Set has a 74 cm extruded aluminium bench, three-position riders, four 50 mm mounted lenses and an LED-illuminated F object for exploring the basic properties of lenses.
Last updated: October 2026
Key Features
- 74 cm extruded aluminium bench with push-on plastic feet and a large scale
- Three-position riders that lock when a part's stem is pushed in
- Four 50 mm diameter mounted lenses: 3 convex, 1 concave
- LED-illuminated F object powered by an AAA battery, with no cables
- Opaque screen with scales
Technical Specifications
| Specification | Value |
|---|---|
| Bench | 74 cm, extruded aluminium |
| Lenses | Four, 50 mm diameter |
| Convex focal lengths | +100mm, +150mm, +200mm |
| Concave focal length | Negative 150mm |
| Object | LED-illuminated F, AAA battery |
| Parts per rider | Up to three |
About This Product
Each optical part sits in a moulded holder with a stem that pushes into a socket on a rider. A rider takes up to three parts and slides freely along the bench until a stem is pushed in, which locks it in place. This stops parts being moved by accident and lets the whole lightweight setup be carried without anything falling off. The self-contained F object forms bright images on the opaque screen.
Frequently Asked Questions
What focal lengths do the lenses have?
The three convex lenses have focal lengths of +100mm, +150mm and +200mm, and the concave lens is negative 150mm. All four are 50mm in diameter.
Does the F object need a power cable?
No. The LED-illuminated F object is self-contained and runs on an AAA battery.
