Hall Effect Apparatus Manufacturer,Supplier and Exporter in India
Product Code : EL-AP-10733
Quick Answer: The Hall Effect Apparatus has an n-type GaAs Hall sensor chip on a two-axis traverse, a Helmholtz coil pair and a control unit with constant current sources for the magnet and the Hall current.
Last updated: October 2026
Key Features
- n-type GaAs Hall sensor chip on a two-axis mechanical traverse for field plotting
- Helmholtz coil pair with a 75mm effective diameter
- Constant current sources: magnet 0-0.5A, Hall driving current 0-3mA
- Relay-controlled reversing switches for studying the removal of systematic errors
- 3-1/2 digit current and voltage meters
- Metal storage case for the Hall Effect board
Technical Specifications
| Specification | Value |
|---|---|
| Sensor | n-type GaAs Hall chip |
| Coils | Helmholtz pair, 75mm effective diameter |
| Central magnetic induction | 11.25mT at 0.5A |
| Magnet current | 0-0.5A |
| Hall driving current | 0-3mA |
| Meters | 3-1/2 digit, current and voltage |
About This Product
The Hall effect is the side-to-side voltage that appears in a conductor or semiconductor carrying a current when it is placed in a magnetic field. With this set the effect is studied in a GaAs semiconductor, the conductivity of the semiconductor is found, and the chip is used to plot the magnetic field of the coils. The reversing switches let several well-known systematic errors be explored and removed. Science Lab Export can supply the Hall Effect Apparatus to Lithuania, Brunei, Laos, Benin and Madagascar.
Frequently Asked Questions
What can be measured with it?
It explores the Hall effect in a GaAs semiconductor, determines the conductivity of the semiconductor and uses the chip to plot the magnetic field of the coils. Systematic errors and their elimination can also be studied.
What field do the coils give?
The Helmholtz coil pair has a 75mm effective diameter and gives a central magnetic induction of 11.25mT at 0.5A.
