EDSPOT Galvanometer Manufacturer,Supplier and Exporter in India
Product Code : EL-AP-11080
The EDSPOT Galvanometer provides high-sensitivity current
and voltage detection for bridge-nulling and low-signal electromagnetic
experiments in University and Vocational laboratories. Engineered with a
taut-suspension movement and integrated light-spot projection, it ensures
parallax-free readings on a translucent screen. Compliant with international
electrical standards, this instrument supports advanced physics curricula
through multi-range attenuation and constant input resistance.
Technical Specifications
|
Tender Specification |
OEM Technical Detail |
|
Movement Architecture |
Integral taut-suspension with transverse vibration damping |
|
Display Interface |
Translucent screen with hairline brilliant light spot
projection |
|
Scale Graduation |
Dual-mode: 0–18 cm (Left Zero) and 9–0–9 cm (Center Zero) |
|
Sensitivity Attenuation |
Four-stage rotary selector: x1, x0.1, x0.01, x0.001 |
|
Input Parameters |
Constant input resistance across all ranges; 4mm
color-coded sockets |
|
Power Requirement |
220–240V AC Mains, 50/60Hz |
|
Control Interface |
Front-panel Lock/Unlock, zero adjustment, and sensitivity
scaling |
Key Pedagogical Outcomes
- Integrated
Taut-Suspension Movement: Allows students to analyze high-sensitivity
electrical deviations with minimal mechanical hysteresis or frictional
error.
- Center
and Left Zero Scale Options: Facilitates the evaluation of
bidirectional current flow in bridge balance experiments and
unidirectional displacement in capacitor discharge modules.
- Four-Stage
Attenuation (x1 to x0.001): Enables learners to apply
appropriate scaling techniques to protect sensitive movements while
approaching null-point synthesis.
- Brilliant
Light Spot Display: Supports the synthesis of experimental data
by providing clear, distant-viewable hairline indications, reducing
observation fatigue during prolonged circuit analysis.
International Logistics & Compliance
Science Lab Export ensures all EDSPOT Galvanometers
are ruggedized for international procurement and transcontinental delivery.
- Packaging:
Export-grade seaworthy crating featuring high-density foam inserts and
anti-static moisture barriers.
- Documentation:
Consignments include Manufacturer’s Authorization Form (MAF), IQ/OQ/PQ
Certification, and comprehensive Technical Manuals in English.
- Durability:
The optical and mechanical systems utilize a tropicalized design, tested
for operational stability in environments up to 45°C and 90%
non-condensing humidity to prevent fungal growth on translucent screens
and internal optics.
