Michelson And Fabry-Perot Interferometer Manufacturer,Supplier and Exporter in India
Product Code : EL-AP-10742
Quick Answer: The Michelson And Fabry-Perot Interferometer has a cast base with a machined and ground lathe bed and a geared mirror drive whose fine knob reads to 0.0001mm.
Last updated: October 2026
Key Features
- Changes between Michelson and Fabry-Perot configurations
- Coarse knob sets the mirror to within 0.01mm on a 205mm divided steel scale
- Graduated fine knob reading to 0.0001mm for displacements and ring counting
- 1mm pitch geared lead screw driving the movable mirror carriage
- Fixed optical parts mounted on vertical steel plates
- Substantial cast base carrying a machined and ground lathe bed
Technical Specifications
| Specification | Value |
|---|---|
| Weight | 50 lbs |
| Dimensions | 26 × 16 × 14 in |
| Coarse setting | To within 0.01mm |
| Fine adjustment | Reads to 0.0001mm |
| Scale | 205mm divided steel |
| Lead screw | 1mm pitch, geared |
About This Product
The instrument can be set up as a Michelson interferometer or changed over to the Fabry-Perot arrangement. Its base is a substantial casting that holds a machined and ground lathe bed at a convenient height for observation. The coarse knob is read on a divided steel scale and a numbered dial for fractions of a millimetre, while the fine knob gives controlled displacements for ring counting.
Frequently Asked Questions
How finely can the mirror be moved?
The coarse knob sets the mirror to within 0.01mm, and the graduated fine knob reads to 0.0001mm.
Can both interferometer types be set up?
Yes. The Michelson and Fabry-Perot configurations are easily interchanged.
Related: Advanced Physics, Laser Optics Demonstrator, Millikan Oil Drop Apparatus, Nuclear Magnetic Resonance Apparatus and Optics.
For a quotation on the Michelson And Fabry-Perot Interferometer, contact Science Lab Export.
