Demonstration Meter, Vertical Manufacturer,Supplier and Exporter in India
Product Code : EL-AP-11078
The Vertical Demonstration Meter is engineered for clear
visualization of moving-coil or moving-iron mechanisms in University and
Vocational laboratories. Operating with a high-contrast 80mm scale, this
instrument facilitates the real-time observation of electromagnetic deflection.
It meets ISO 9001:2015 manufacturing standards, providing a ruggedized
instructional platform for analyzing current and voltage measurement principles
in international science curricula.
Technical Specifications
|
Tender Specification |
OEM Technical Detail |
|
Material Grade |
Ruggedized clear acrylic housing; Impact-resistant wooden
stand |
|
Scale Length |
80 mm (approx.) |
|
Overall Dimensions |
115 x 115 x 175 mm (approx.) |
|
Orientation |
Vertical high-visibility mount |
|
Mounting |
Stable laminated wooden base |
|
Mechanism Accessibility |
Fully transparent enclosure for internal component viewing |
Key Pedagogical Outcomes
- Transparent
Enclosure: Allows students to identify and analyze the
interaction between the permanent magnet, hairspring, and moving coil,
supporting Electromagnetism Module 201.
- 80mm
High-Contrast Scale: Enables learners to demonstrate
parallax-free readings and verify linear vs. non-linear scale
distributions in analog metering.
- Vertical
Stand Orientation: Facilitates large-group observation, allowing
instructors to explain gravitational vs. magnetic torque effects on
needle deflection.
- Exposed
Terminal Connections: Supports the synthesis of shunt and
multiplier circuit configurations to observe real-time conversion between
ammeter and voltmeter functions.
International Logistics & Compliance
Science Lab Export ensures that all Demonstration
Meters are prepared for rigorous international transit and varying climate
conditions.
- Packaging:
Export-grade seaworthy crating featuring shock-absorbent internal bracing
and moisture-barrier secondary containment.
- Documentation:
Shipments include Manufacturer’s Authorization Form (MAF), IQ/OQ/PQ
Certification, and User Manuals in English.
- Durability:
Tropicalized design featuring anti-corrosive treatments on all metallic
windings and terminals, tested for operational integrity in environments
up to 45°C and 90% humidity.
